Project Name: Pre Engineered Structural Steel Warehouse
Location: Romania
Area: 996 m2
Project Time: 2009
Pre engineered warehouse details:
1. Size: 48.24*20.65*7.3m(Length*Width*Eave Height)
2. Primary steel structure: Q345B H section steel column, beam and mezzanine beam with oxide primier and grey facing painting;
3. Structural steel warehouse secondary framing: C section steel purlin, tie bar, roof and wall support, bracing are formed as secondary framing
4. Roof panel: EPS Sandwich Panel, Thickness=50mm
5. Wall panel: EPS Sandwich Panel, Thickness=50mm
6. Door: E-rolling door
7. Window: Aluminium-alloy window
8. Skylight panel on pre engineered warehouse: thickness=1.5mm
