Industrial steel frame workshop features:
1. Beautiful appearance
2. Structural safety and reliability, earthquake resistance up to 9 grade
3. Steel frame workshop has long life span: 50 years
4. Construction is fast, time-saving and labor-saving
5. Environmental friendly
Metal frame workshop description:
Steel metal workshop main framing part:
Column and beam: Q345B, welded H section steel with two coats of red lead paint
Endwall and parapet wall column: Q235B, welded H section steel with two coats of red lead paint
Purlin: Q235, galvanized C section steel
Steel frame workshop protection part:
Exterior roof sheet: V-760, 0.5mm dip aluminum-zinc steel sheet
Roof panel insulation layer: 75mm, fiberglass wool sandwich panel（12㎏/m³）with aluminum foil paper
Interior roof: coated wire mesh
Metal frame workshop skylight sheet: V-760, 1.2mm / V-900, 1.0mm / V-780, 1.2mm
Exterior wall sheet: V-780, 0.5mm dip aluminum-zinc horizontal steel sheet
roof ridge tile: 0.5mm galvanized steel sheet
Steel metal workshop window and Door
Door: EPS sandwich panel sliding door
Window: aluminum alloy window
Service: industrial metal frame workshop design, steel metal fabrication and workshop construction.
