China Logistics Warehouse

Views: 573     Author: Site Editor     Publish Time: 2018-03-19      Origin: Site

facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button

Project Name: Steel Structure Logistics Warehouse for Hisense Household Appliances

Location: China

Area: 117000 m2

Project Time: 2014

Project details:

The logistics warehouse project is used as Hisense Logistic Park, mainly engaged in Hisense (Shandong) home appliance industry park, warehousing, transit and other logistics transportation. Our company used 25 days finished installation of the steel warehouse project, get government and Hisense Group  highly praise.

1. Structure type: single layer portal frame

Size: The Logistic warehouse project contains 5 single warehouse, #1 15000 m2, #2 15000 m2, #3 45000 m2, #4 27000 m2, #5 15000 m2

2. Eave height: 8.2m

3. Main steel frame: H columns and beams with grey painting

4. Secondary Structure: Z purlins with galvanized surface treatment

5. Roof Material: 760 type, 0.6mm Corrugated steel sheet+ Fiber glass wool insulation (The longest roof panel is nearly 80 meters)

6. Wall Material: Corrugated steel sheet with thickness of 0.6mm

7. Door: Electric rolling door

Hisense Logistic Warehouse.jpg

steel structure warehouse installation team.jpg

Steel Structure Logistics Warehouse

Warehouse roofing panel installation.jpg

warehouse steel frame.jpg

Warehouse Roofing.jpg

Logistics Warehouse

Finished Hisense Logistics Warehouse.jpg

The logistic warehouse is working well now
