Mauritius Factory Building Project

Views: 625     Author: Site Editor     Publish Time: 2020-04-16      Origin: Site

facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button

Project Name: Prefab Steel Factory Building

Location: Mauritius

Area: 12452 m2

Project Time: 2016


Prefab factory building details:

1. Size: 123.75*91.2*12.274m (Length*Width*Eave Height)

2. Roof truss, Steel Column and Beam: Hot-dip galvanized,83um

3. Factory building purlin: C section steel with hot-dip galvanized

4. Roof cladding: 0.6mm corrugated steel sheet+50mm glass-wool insulation

5. Wall cladding: 3m brick wall+0.6mm corrugated steel sheet

prefab steel factory building design

steel structure of factory building unloading

Prfab Steel Factory Building

Prefab Factory Building

Steel Factory Building

Steel Ladders of Steel Factory Building

Prefab Steel Factory Building

Steel Framework of Factory Building

Mauritius Project - Prefab Steel Factory Building

MPA Steel Shed Project in Mauritius

MPA Steel Shed in Mauritius
