Niger Aircraft Hangar Project

Views: 264     Author: Site Editor     Publish Time: 2018-08-10      Origin: Site

facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button

Project Name: Prefab Steel Structure Aircraft Hangar

Location: Niger

Area: 2452 m2

Project Time: 2016

Steel structure hangar details:

Steel hangar adopts Steel Portal Frame + Space Truss Structure System, contains 6 sets prefab hangars, used in Niger Army.

1. Big steel hangar: 60*40*8m  with 40m2 partial floor(Length*Width*Eave Height)*2 sets, the hangar door size :38*6.5m

2. Small steel hangar: 30*20*8m (Length*Width*Eave Height)*4 sets, the hangar door size: 18*6.5m

3. Bay spacing: 40m

4. Eave height: 8m

5. Ridge height: 9m

6. Amount of steel materials: 115 ton

7. Frame type: gate-type steel frame office with 2 floors. Gate opening framed by pipe truss, quantities of electrical folded pushing gates

8. Main steel framework: H section steel column and beam with 2 times mid-grey anti-rusting painting.  Galvanized C Purlin for roof and wall

9. Support part: tie bar, roof and wall support, bracing, knee bracing, sleeve pipe and angle steel

10. Roof materials: V-960 Insulated Steel Sandwich Panel, 0.4mm/50mm glass wool/0.5mm,glass wool=60kg/m3, white

11. Wall materials: V-900 single steel sheet, 0.6mm thick, white

12. Windows: aluminium-alloy Window

13. Door: professional hangar door and steel door

14. We assign our workers to do the hangar installation with local workers together

aircraft hangar structural design

packing and shipping of steel structure hangarspace frame hangar construction

steel frame of hangar

Steel Hangar

Aircraft Hangar

Prefab Hangar

Prefab Steel Structure Aircraft Hangar
