Features:
1. Structural type: portal frame steel structure
2. Antirust and lightweight
3. Good ventilation and insulation effective
Prefabricated pig house details:
1. Size: 66*13*3m(Length*Width*Eave Height)
2. Ridge height: 4.72m
3. Steel amount: 22 ton
4. Prefabricated pig house main steel framing: Q235B, H column and beam with hot-dip galvanized
5. Roof and wall purline: Q235, C section steel with galvanized
6. Supporting part: tie bar, column bracing, horizontal bracing, knee-bracing, tension rod, angle steel, all these will improve the stability and durability of the whole structural building
7. Roof panel: V-960,0.5mm/100mmEPS/0.5mm
8. Wall panel: V-950, 0.5mm/100mmEPS/0.5mm
9. Door: EPS sandwich panel sliding door
