Project Name: Steel Structure Workshop with Crane

Location: Senegal

Area:1400 m2

Project Time: 2009

Senegal steel workshop details:

1. Size: 50*24*12m (Length*Width*Eave Height)

2. Main steel structure included Crane Beam: welded H section steel with anti-rusting grey painting

3. Secondary steel framing: Purlins, girts and eave struts are secondary structural members used to support the wall and roof panels.

4. Roof and wall cladding: single steel sheet, thickness=0.5mm, blue color.

5. Brick wall: 3m height.

6. Lifting capacity of crane: 15T*1 set+7T*1 set

7. Service: structural steel fabrication, steel structure workshop design and erection..

Senegal steel structure workshop project

framework of steel structure workshop project in Senegal

Senegal steel workshop project

steel structure workshop

Axis elevation drawing of steel structure workshop design
